Tongsheng TSDZ8 Mid Motor Kit 48 V 750 W Battery 48 V 20 Ah 960 Wh Touch Display VD18MT 1.45" Brake Sensor Black For Electric Bicycle
You already have the maximum available quantity in your cart.
This kit for converting a traditional bicycle into an electric bike includes a mid motor Tongsheng TSDZ8 48 V 750 W, a battery, a touch display VD18MT, and a brake sensor. The motor is installed in the bottom bracket of the frame, making it a mid-drive electric kit. Power is provided by a 48 V 20 Ah battery with an energy capacity of 960 Wh designed to be mounted on the down tube. Riding data is displayed on the touch screen VD18MT with a diagonal of 1.45", which is operated directly by touching the screen. The battery comes in black and is charged using a 54.6 V 3 A charger.
Main Features
- Mid Motor – Tongsheng TSDZ8 with a voltage of 48 V and a power of 750 W is installed in the bottom bracket of the bicycle.
- Battery Capacity – the battery operates at a voltage of 48 V and a capacity of 20 Ah, corresponding to a total energy of 960 Wh.
- Battery Cells – the battery is composed of cylindrical cells of format 21700.
- BMS Protection – the electronic battery management system BMS 30 A monitors the operation of the battery during riding and charging.
- Life Span – the battery is designed for 1000 charging cycles.
- Dimensions and Weight – the battery measures 365 x 85 x 107 mm and weighs 5.0 kg.
- Placement – downtube type battery is mounted on the down tube of the bike.
- Durability – the battery casing has an IP65 rating and is protected against damage from falls.
- Connection – the battery holder with 6 pins is equipped with a cable ending in an XT60 (male) connector for connection to the motor's control electronics.
- Charger – output voltage 54.6 V and charging current 3 A, the mains plug is part of the cable.
- Display – touch screen VD18MT with a diagonal of 1.45" for displaying riding data on the handlebars.
- Brake Sensor – used to interrupt the motor operation when the brake lever is pressed.
- USB – the battery is not equipped with a USB output for charging other devices.
Package Contents:
- 1x Tongsheng TSDZ8 48 V 750 W mid motor
- 1x 48 V 20 Ah 960 Wh battery
- 1x battery holder with 6 pins
- 1x 54.6 V 3 A charger
- 1x touch display VD18MT 1.45"
- 1x brake sensor
This electric kit is designed for converting a bicycle into an electric bike with a mid-drive power of 750 W. The battery with dimensions 365 x 85 x 107 mm and a weight of 5.0 kg is secured to the down tube in a holder with 6 pins and connects with an XT60 connector. The battery with 21700 cells offers an energy capacity of 960 Wh and is designed for 1000 charging cycles. With an IP65 rating, the battery is protected against dust and splashing water, making it suitable for riding in wet conditions. The touch display VD18MT and brake sensor complete the kit with a clear overview of riding data and motor shutdown when braking.
