JNFN S Bluetooth BMS Balancing Module 17S to 24S 420 A Peak 1050 A for Li-ion LiFePO4 LTO and Na-ion Silver for E-bikes and Scooters
You already have the maximum available quantity in your cart.
The JNFN Balancing BMS Module is designed for the management and protection of batteries in e-bikes and electric scooters with very high current demands. It supports connections of 17S to 24S, meaning batteries with 17 to 24 cells in series. The module offers a continuous current of 420 A and a short-term peak of 1050 A. It is equipped with Bluetooth connectivity and cell balancing functionality. Power wires connect directly to the screw terminal points on the sides of the silver casing.
- Range 17S to 24S: the module is intended for batteries with 17 to 24 cells connected in series, suitable for high-voltage assemblies.
- Continuous current 420 A: compare this value with the maximum consumption of the motor and controller before installation.
- Peak current 1050 A: according to the label, the module can handle a peak of 1050 A for 10 seconds.
- Screw terminal points: six terminal points with screws, three on each side of the module, are used for connecting power wires. The cross-section of the wires should be selected according to the current load of the battery.
- Bluetooth and TTL/BLE port: the module communicates wirelessly via Bluetooth, with a TTL/BLE port also indicated on the label.
- Cell balancing: the function equalises the voltage between individual cells of the battery.
- Cell types: the module is suitable for Li-ion, LiFePO4, LTO and Na-ion batteries.
- Cell connectors: a series of connectors on the top edge of the module is used for connecting wires to individual cells.
- Casing: the flat design in a silver casing facilitates storage next to cells in the battery box.
- Model designation: 24ZHE-24-420A, as indicated on the module label.
Package contents:
- 1x JNFN Balancing BMS Module 17S to 24S 420 A
The JNFN Balancing BMS Module is designed for building or repairing a battery for an e-bike or electric scooter with 17 to 24 series cells. The continuous current of 420 A with a peak of 1050 A covers even very high current demands of the drive. Power wires connect via screw terminal points, allowing the use of cables suitable for the load. The module supports Li-ion, LiFePO4, LTO and Na-ion cells and is equipped with Bluetooth connectivity with balancing functionality. Before installation, ensure that the number and type of cells and the current consumption match the module's specifications.
