Frequency Converter for Motor Speed Control, 0.75 kW, 380 V, 0.1-400 Hz, 20x13x10 cm, Dark Grey, for Industrial Motors and Machines

Frequency Converter for Motor Speed Control, 0.75 kW, 380 V, 0.1-400 Hz, 20x13x10 cm, Dark Grey, for Industrial Motors and Machines

Three-phase frequency converter 380 V for smooth speed control of asynchronous motors. Suitable for machines, fans, pumps, and small production lines. Full description
In stock
Delivery €1.59
30-day return policy
€163.71
Safe shopping Safe shopping
Overview
Frequency Converter for Motor Speed Control, 0.75 kW, 380 V, 0.1-400 Hz, 20x13x10 cm, Dark Grey, for Industrial Motors and Machines

This version of the frequency converter is designed for connection to a three-phase industrial network of 380 V and is used to control the speed of motors with a power of up to 0.75 kW. The terminal block at the top of the device accepts input wires L, N, and earth, while the output terminals U, V, and W supply the motor with regulated three-phase voltage. The operating range from 0.1 to 400 Hz allows the operator to precisely set the speed according to the requirements of specific technology. The LED panel with a four-digit display shows the current frequency, adjustable parameters, and drive status messages. The housing, measuring 20 x 13 x 10 cm, is designed for safe mounting in a control cabinet or on a solid wall of the machine.

Features:

  • Power 0.75 kW for smaller three-phase motors powered at 380 V
  • 380 V three-phase power supply with input terminals L, N, and earth
  • Frequency 0.1–400 Hz for low-speed and high-speed applications
  • LED panel with control buttons PRG, M-FUNC, ENTER, RUN, STOP, and arrows
  • Terminals U, V, W for the motor supplemented with P+ and PB for braking resistor
  • Rotary knob for smooth manual frequency adjustment
  • Indicator lights for easy identification of the current operating mode
  • Functional button with a symbol for quick switching between parameters
  • Additional signal terminal block for external switches and sensors
  • Warning DANGER 5 min for residual voltage in the intermediate circuit after shutdown

Contents of the package:

  • 1x frequency converter 0.75 kW
  • 1x user manual

The converter is a solution for operations with a standard industrial network of 380 V, where there is a need to change the speed of smaller motors for conveyors, fans, or pumps. Smooth control reduces shocks during startup, saves machine mechanics, and energy consumption during partial load. Programmable parameters allow adapting the ramp for starting and braking to the specific type of driven equipment. The robust terminal block with a protective cover supports safe installation directly in the production environment. Suitable applications include automation of smaller lines, modernisation of existing machines, assemblies of industrial pumps, and drives for ventilation equipment in workshops.
