DDR5 Memory Module 135 x 41 mm 16 GB 5600 MHz CL46 1.1/1.25 V with PMIC and On-Die ECC Grey for Gaming PCs with Intel and AMD Boards

DDR5 Memory Module 135 x 41 mm 16 GB 5600 MHz CL46 1.1/1.25 V with PMIC and On-Die ECC Grey for Gaming PCs with Intel and AMD Boards

Sixteen gigabytes of DDR5 at 5600 MHz for gaming and video editing. XMP 3.0 and EXPO profiles, voltage 1.1/1.25 V and a grey cover measuring 135 x 41 mm. Full description
In stock
Delivery €1.59
30-day return policy
€433.14
Safe shopping Safe shopping
Overview
DDR5 Memory Module 135 x 41 mm 16 GB 5600 MHz CL46 1.1/1.25 V with PMIC and On-Die ECC Grey for Gaming PCs with Intel and AMD Boards

The DDR5 memory module with a capacity of 16 GB is designed for gaming and workstation desktop computers built on Intel and AMD platforms with DDR5 slots. It combines 16 GB with a frequency of 5600 MHz and a latency of CL46, making it a suitable foundation for gaming, streaming, and video editing. The module supports Intel XMP 3.0 and AMD EXPO profiles, which allow the declared frequency to be activated in the BIOS with a single choice. The dimensions including the cover are 135 x 41 mm. The grey cover is complemented by light elements and cut-outs on the top edge.

  • Two voltage levels – in default mode, the memory operates at a voltage of 1.1 V, which corresponds to the basic DDR5 specification. After activating the XMP 3.0 or EXPO profile, the voltage increases to 1.25 V to ensure the module runs stably at the full 5600 MHz.
  • Capacity of 16 GB – the volume covers current games along with a browser, communication applications, and recording software running in the background. It is also suitable for photo editing and video editing in smaller projects.
  • Power regulation on the module – the voltage distribution is managed by a dedicated PMIC chip mounted directly on the memory. The motherboard supplies only the input power, while the memory itself takes care of fine regulation.
  • On-Die ECC – the DDR5 memory chips correct errors occurring in the cells directly within the chip. This is not server-grade ECC memory with processor-level control, but a built-in feature of the DDR5 standard.
  • Two sub-channels – the module is divided into two independent 32-bit sub-channels and operates with eight groups of banks, which is double that of DDR4. This allows the memory controller to handle more requests concurrently.
  • Dual-channel configuration – in a pair with an identical module, a 32 GB dual-channel setup is created, which will benefit demanding games, 3D graphics, and virtualisation.
  • Height of the cover 41 mm – it is advisable to check before installation whether the CPU cooler does not extend above the memory slots.

Contents of the package:

  • 1x DDR5 memory module 16 GB 5600 MHz

The 16 GB DDR5 module with a frequency of 5600 MHz is primarily intended for gaming setups and more powerful workstations. Without any adjustments, it will run in basic mode, while full speed is unlocked by the XMP 3.0 profile on Intel boards or EXPO on AMD boards. Installing it into a DDR5 slot can be done by anyone who knows how to remove a case side panel, as you simply push the module until the latches click into place. The module is not compatible with DDR4 slots due to the differently positioned notch. Thanks to compatibility with both Intel and AMD motherboards supporting DDR5, it is suitable for a wide range of new builds.
