Small Ratchet Spanner 6 mm with Ring and Open End with Fine Ratchet with 72 Teeth and Body 127 mm in Dark Grey Finish for Precision Mechanics
Small Ratchet Spanner 6 mm with Ring and Open End with Fine Ratchet with 72 Teeth and Body 127 mm in Dark Grey Finish for Precision Mechanics 1

Small Ratchet Spanner 6 mm with Ring and Open End with Fine Ratchet with 72 Teeth and Body 127 mm in Dark Grey Finish for Precision Mechanics

The six holds small terminal covers and model parts. The ratchet in the ring catches another tooth after five degrees, and the 127 mm body fits even where space is limited. Full description
In stock
€21.79
Safe shopping Safe shopping
Overview
Small Ratchet Spanner 6 mm with Ring and Open End with Fine Ratchet with 72 Teeth and Body 127 mm in Dark Grey Finish for Precision Mechanics

The six is the finest size used in a typical workshop. It appears on terminal blocks and enclosures on electronics covers in models and modelling techniques, on small furniture fittings, and on cable clips in cars. Screws of this size are tightened by feel, not by force, which is why the short body of 127 mm allows for good torque estimation. The closed end carries the ratchet, and the gearing with 72 teeth catches a new engagement after just five degrees of rotation, allowing the nut to move even when the hand shifts only by a centimetre. The open end, on the other hand, reaches connections accessible only from the side. The ring has a width of 18.5 mm with a thickness of 8 mm, the open end measures 15 mm and is 6 mm thick. The surface is dark grey, the ratchet ring is gold-coloured, and the number 6 is stamped on both sides of the arm. The arm is flat and slightly curved near the head, allowing it to run closely along the cover or plate.

  • Ratchet in Ring 6 mm — a small nut can be threaded without repeatedly removing the spanner, saving the most time in precision mechanics.
  • Engagement after 5° — fine division works even between conductors and plastic parts, where the arm cannot be pulled out at all and a traditional spanner needs to be switched after each pull.
  • Short Body 127 mm — the small lever helps maintain sensitive tightening and protects the delicate thread from over-tightening, which can easily occur here.
  • Open End 15 mm — the open end with a thickness of 6 mm reaches nuts on clips and terminals accessible only from the side, around which the ring cannot be threaded.
  • Direction Switching — the lever in the ring changes the ratchet's direction, so one engagement is sufficient for loosening and tightening without turning the spanner in hand.
  • Ring Thickness 8 mm — the head grips the screw all around and distributes the force on the edges, which is crucial for soft materials.
  • Stamped Number 6 — the marking on both sides of the arm helps identify the smallest spanner among others in the bag and drawer.

Contents:

  • 1x Ratchet Spanner 6 mm

This tool is useful in electrical engineering for model work, during bicycle servicing, and in furniture assembly and small constructions. It is also handy for repairs of appliances and home technology, where the same size recurs on covers and holders. The ratchet side speeds up threading and tightening; for a rusty or previously over-tightened screw, it is better to use a solid spanner, as the fine gearing is not designed for impact loading. The ring must be fully engaged, otherwise, the torque is transferred to the edge and the softer screw gets deformed. For connections of this diameter, very little force is sufficient, so it pays off to tighten slowly and check the resistance. The ring thickness of 8 mm keeps the gearing firmly engaged, and the head remains shape-stable even after prolonged use. It is advisable to protect the mechanism from dust and moisture and occasionally blow it out with a drop of oil. The dark grey surface with a gold ring is easy to wipe clean, and the spanner can be hung on a panel or stored in a bag pocket with larger sizes.

Price incl. VAT €21.79
