Shank Cutter 5 x 22 mm Straight Grooving Three-Flute TCT Shank 12.7 mm 1/2 inch Tungsten Carbide Blades Silver-White Wood and Chipboard
You already have the maximum available quantity in your cart.
The shank cutter with dimensions 5 x 22 mm is a straight grooving cutter for milling narrower grooves and cut-outs in wood. It features three tungsten carbide (TCT) blades, a cutting diameter of 5 mm, and blade lengths of 22 mm. It is clamped with a shank diameter of 12.7 mm, or 1/2 inch, into a router, CNC milling machine, or engraving machine. It is designed for wood and multilayer chipboard. The shank is silver, the part near the blades is white, and there is a black ring on the shank.
- Cut width of 5 mm — the cutter creates a groove 5 mm wide with a flat bottom and vertical walls. It is suitable where a standard 6 mm groove is too wide.
- Depth up to 22 mm — blades 22 mm long allow for milling deeper grooves. For a narrow cutter, gradually increase the depth in multiple passes to avoid overloading the tool.
- Three working blades — during rotation, three blades gradually engage in the cut, each removing smaller chips. The cut is therefore smoother than with cutters with fewer blades.
- Tungsten carbide cutting edges — the cutting edges are made of tungsten carbide, abbreviated as TCT. This material is harder than tool steel and is commonly used in wood cutters.
- Clamping in a 12.7 mm collet — the shank with a diameter of 1/2 inch fits into a 12.7 mm collet. Do not clamp it into a 12 mm collet, as it would not hold securely. Therefore, check your router's equipment before purchasing.
- Overall dimensions — the cutter is 71 mm long. The thick shank provides good rigidity in the collet, and choose the depth of insertion according to your machine's instructions.
- For routers and CNC — the cutter can be used in a handheld router, in a milling table, in a CNC milling machine, or in an engraving machine with a 1/2 inch collet.
- Finer joints — the narrower groove is suitable for embedding thinner boards, strips, and infills in wood and multilayer chipboard. You will use it when making furniture, boxes, and frames.
- Protection during work — securely tighten the cutter, safely clamp the workpiece, and choose an appropriate feed rate. Always wear protective glasses when milling.
- Contents of the package — 1x shank grooving cutter 5 x 22 mm with a 12.7 mm shank.
The shank cutter 5 x 22 mm is suitable for narrower straight grooves and cut-outs in wood and multilayer chipboard. The blade length of 22 mm allows for milling deeper grooves, provided the depth is added gradually. Three tungsten carbide TCT blades remove material smoothly and create a groove with a flat bottom. The 1/2 inch shank is clamped into a router, CNC milling machine, or engraving machine. You will use the cutter when making furniture and small wooden products.
