Self-Priming Membrane Pump for Motorhomes and Boats 12 V with 40 PSI Pressure and 3.8 L per Minute Flow in Black-Orange Design
You already have the maximum available quantity in your cart.
The self-priming membrane pump delivers water under pressure in motorhomes, boats, and small distributions. A pressure of 40 PSI corresponds to 2.8 bar, and the pressure switch turns off the pump at this value. A flow rate of 3.8 L per minute applies with a tolerance of 10 percent. Power is provided by a direct current voltage of 12 V, and the consumption is around 2 A. The motor is a direct current type with a permanent magnet, and the ports have a diameter of 3/8 inch.
- Pressure 40 PSI — converted to 2.8 bar, the cut-off pressure is specified in the range of 40 to 45 PSI.
- Adjustable Pressure — the pressure value can be adjusted on the pump.
- Flow Rate 3.8 L per Minute — with a tolerance of ±10 percent.
- Power Supply 12 V — direct current voltage, current 2 A and maximum 4 A.
- Self-Priming — suction height is 1.8 m.
- Ports 3/8 Inch — the internal diameter of the connections is 10.5 mm.
- Pressure Switch — the switch is fully automatic.
- Membrane Construction — the pump is of membrane type.
- Motor with Permanent Magnet — the drive is provided by a direct current motor.
- Noise Level Up to 70 dB — operating noise is specified up to 70 dB.
- Media Temperature — the pump is designed for liquids from 5 to 60 °C.
- Ambient Temperature — operating environment is specified in the range of 5 to 40 °C.
- Suitable Liquids — water and weakly acidic or alkaline liquids with pH 4 to 10 without hard particles.
- Flow Rate According to Pressure — at zero pressure 3.84 L per minute, at 1.4 bar 3 L per minute.
- Consumption According to Pressure — from 1.85 A at zero pressure to 3.16 A at 2.8 bar.
- Dimensions 154 x 79 mm — the base has a width of 98 mm and the height of the pump is 73.5 mm.
- Hole Spacing 55 mm — mounting holes have a diameter of 5 mm.
- Mounting Feet — four feet are provided for screwing the pump.
- Supply Wires — a pair of colour-coded wires comes from the motor.
- Power Supply via Transformer — the pump must not be connected to 220 V without a transformer.
- Warning on Label — the pump is not designed for flammable liquids.
- Black-Orange Design — the motor is black, the pumping head is orange.
Contents of the Package:
- 1x self-priming membrane pump
The pump is suitable for water distributions in motorhomes, caravans, and boats. Ports 3/8 inch with an internal diameter of 10.5 mm correspond to a standard hose of this size. Media temperature of 5 to 60 °C can be water or weakly acidic or alkaline liquid with pH 4 to 10. A suction height of 1.8 m means that the pump can draw water from a lower tank. Dimensions of 154 x 79 mm and hole spacing of 55 mm determine how much space the pump will occupy.
