Frequency Converter 4 kW 220 V Single-Phase Input Three-Phase Output Current 15 A Frequency 0-400 Hz Vector and V/F Control Grey for Motor
You already have the maximum available quantity in your cart.
The frequency converter with 4 kW power serves for smooth speed regulation of a three-phase motor. It is powered from a single-phase 220 V supply and delivers three-phase voltage to the motor at the output, allowing you to start a three-phase machine even where only a standard phase is available. The output current reaches 15 A and the frequency can be set in the range of 0 to 400 Hz. The device supports both vector and V/F control, enabling precise speed regulation as well as simpler operation. The front panel features a display with buttons and a rotary control, and the body is dark grey.
Features:
- 4 kW Power — speed control for three-phase motors.
- Input Voltage 220 V — connection to a single-phase supply.
- Three-Phase Output — powering a three-phase motor at terminals U, V, and W.
- Output Current 15 A — operational current of the converter.
- Frequency 0-400 Hz — wide range of speed settings.
- Vector and V/F Control — precise regulation and simple operation.
- Rotary Control — quick frequency adjustment directly on the panel.
- LED Display — showing frequency and operational values.
- Control Buttons — PRG/SET, JOG/ESC, arrows, RUN and STOP/RES.
- JOG Function — step control of the motor for adjustment.
- Cooling Fan — heat dissipation at the top of the body.
- Grey Colour — dark grey body with mounting elements.
Package Contents:
- 1x frequency converter
The converter is suitable for pumps, fans, conveyors, machining tools, and other devices with a three-phase motor where you need to smoothly regulate the speed. Single-phase input 220 V with three-phase output allows operation of a three-phase motor even in locations without a three-phase connection. Vector and V/F control allows you to choose between precise regulation with high torque and simple operation depending on the type of machine. The frequency range of 0 to 400 Hz also provides room for high-speed applications, such as spindles. The rotary control and buttons on the front panel facilitate frequency and speed settings.
